Installation conditions
Installation conditionsInstallation conditions
Installation conditions
Inlet / outlet runs None required
Materials
Stainless Steel (316 / 316L) meter
Stainless Steel (316 / 316L) meterStainless Steel (316 / 316L) meter
Stainless Steel (316 / 316L) meter
Measuring tubes / Flanges Stainless Steel AISI 316 / 316L (1.4401 / 1.4404) dual certified
Spigots Stainless Steel CF3M (1.4409)
Bridge Stainless Steel AISI 304 / 304L (1.4301 / 1.4307) dual certified or AISI 316 /
316L (1.4401 / 1.4404) dual certified
Outer casing Stainless Steel AISI 316 / 316L (1.4401 / 1.4404) dual certified
Stainless Steel (S31803) meter
Stainless Steel (S31803) meterStainless Steel (S31803) meter
Stainless Steel (S31803) meter
Measuring tubes / Flanges Stainless Steel UNS 31803 (1.4462)
Spigots Stainless Steel J92205 (1.4470)
Bridge Stainless Steel AISI 304 / 304L (1.4301 / 1.4307) dual certified or AISI 316 /
316L (1.4401 / 1.4404) dual certified
Outer casing Stainless Steel AISI 316 / 316L (1.4401 / 1.4404) dual certified
Hastelloy
HastelloyHastelloy
Hastelloy® C22 meter
C22 meter C22 meter
C22 meter
Measuring tubes / raised face Hastelloy® C22
(Backing) flanges Stainless Steel AISI 316 / 316L (1.4401 / 1.4404) dual certified
Bridge Stainless Steel AISI 316 / 316L (1.4401 / 1.4404) dual certified
Outer casing Stainless Steel AISI 316L (1.404) dual certified
Heating jacket version
Heating jacket versionHeating jacket version
Heating jacket version
Heating loop and insulation jacket Stainless Steel AISI 316 (1.4401)
All versions
All versionsAll versions
All versions
Junction box (remote version) Die-cast Aluminium (polyurethane coating)
Optional Stainless Steel 316 (1.4401)
Process connections
Flange
FlangeFlange
Flange
DIN (EN 1092-1 2007) DN10…300 / PN16…160
ASME (B616.5) ½...12" / ASME 150…1500
JIS (2220 2001) 10A...300A / 10...20K (10K maximum allowable temperature 300°C / 572°F)
Hygienic (08...50 only)
Hygienic (08...50 only)Hygienic (08...50 only)
Hygienic (08...50 only)
Tri-clover ¾...3"
Tri-clamp DIN 32676 DN15..80
Tri-clamp ISO 2852 1...3"
DIN 11864-2 Form A (female) DN15...80
Male thread DIN 11851 (threaded
sanitary connection)
DN15...80
Male thread SMS 25...76 mm / 1...3"
Electrical connections
Electrical connections For full details, including: power supply, power consumption etc., see
technical data for the relevant signal converter.
I/O For full details of I/O options, including data streams and protocols, see
technical data for the relevant signal converter.
