2.9 Installation conditions
2.9.1 Inlet and outlet
2.9.2 T-section
1 path flowmeter
Figure 2-8: Recommended inlet and oulet for d DN80 / 3"
1 t 20 DN
2 t 3DN
2 path flowmeter
Figure 2-9: Recommended inlet and oulet for t DN100 / 4"
1 t 10 DN
2 t 3DN
Figure 2-10: Distance behind a T-section
1 2 path t 10 DN, 1 path t 20 DN
