4 TECHNICAL DATA
30
OPTISONIC 7300
www.krohne.com 09/2018 - 4002312802 - QS OPTISONIC 7300 R04 en
4.1.2 Signal converter housing
Figure 4-2: Dimensions of signal converter housing
1 Compact version (C)
2 Field housing (F) - remote version
Version Dimensions [mm] Weight
[kg]
a b c d e g h
C 202 120 155 260 137 - - 4.2
F 202 120 155 - - 295.8 277 5.7
Table 4-8: Dimensions and weight in mm and kg
Version Dimensions [inch] Weight
[lb]
a b c d e g h
C 7.75 4.75 6.10 10.20 5.40 - - 9.30
F 7.75 4.75 6.10 - - 11.60 10.90 12.60
Table 4-9: Dimensions and weight in inch and lb
INFORMATION!
The weight of a field stainless steel converter housing is 14 kg / 30.9 lb
