TECHNICAL DATA 4
29
OPTISONIC 7300
www.krohne.com09/2018 - 4002312802 - QS OPTISONIC 7300 R04 en
ASME 900 lb
Nominal
size
Dimensions Approx. weight
L H W
Di
1
[inch] [mm] [inch] [mm] [inch] [mm] [inch] [mm] [lb] [kg]
2" 17.7 450 8.7 222 11.5 300 1.7 43 64 29
2.5" 18.1 460 9.6 244 12.0 310 2.3 59 86 39
3" 23.6 600 9.9 251 12.5 324 2.6 67 119 54
4" 26.8 640 11.4 290 13.0 337 3.4 87 157 71
5" 26.8 680 12.6 333 13.7 359 4.6 116 240 109
6" 28.7 730 14.3 363 15.0 381 5.5 140 335 152
8" 26.8 680 17.0 433 18.5 470 7.2 183 545 247
10" 29.9 760 19.6 498 21.5 546 9.1 230 838 380
12" 31.9 810 21.9 556 24.0 610 10.7 273 1168 530
14" 33.9 860 23.1 588 25.2 641 11.8 300 1382 627
Table 4-7: Dimensions and weight in inch / mm and lb / kg
1 Di = inner diameter at flange face. Inner tube diameter may be smaller.
