KROHNE OPTISONIC 7300 - ASME 300 lb Flow Sensor Dimensions and Weight; ASME 600 lb Flow Sensor Dimensions and Weight

4 TECHNICAL DATA
28
OPTISONIC 7300
www.krohne.com 09/2018 - 4002312802 - QS OPTISONIC 7300 R04 en
ASME 300 lb
ASME 600 lb
Nominal
size
Dimensions Approx. weight
L H W
Di
1
[inch] [mm] [inch] [mm] [inch] [mm] [inch] [mm] [lb] [kg]
2" 15.0 380 7.7 196 11.8 300 2.1 53 27 12
2.5" 15.4 390 8.5 217 12.2 310 2.5 63 38 17
3" 21.3 540 9.3 235 12.8 324 3.1 78 53 24
4" 22.4 570 10.7 271 13.3 337 4.0 102 86 39
5" 24.0 610 11.7 298 14.1 364 5.1 128 115 52
6" 25.2 640 13.0 331 15.0 387 6.1 154 146 66
8" 22.0 560 15.3 388 16.6 429 8.0 203 207 94
10" 25.2 640 17.6 448 18.3 474 10.0 255 309 140
12" 28.0 710 20.1 511 20.5 521 11.9 303 452 205
14" 29.9 760 22.0 559 23.0 584 13.1 333 609 276
16" 31.9 810 24.3 616 25.5 648 15.0 381 785 356
18" 33.1 840 26.5 673 28.0 711 16.9 428 926 420
20" 36.6 930 28.8 731 30.5 775 18.8 478 1237 561
24" 38.2 970 33.5 851 36.0 914 22.6 575 1715 778
Table 4-5: Dimensions and weight in inch / mm and lb / kg
1 Di = inner diameter at flange face. Inner tube diameter may be smaller.
Nominal
size
Dimensions Approx. weight
L H W
Di
1
[inch] [mm] [inch] [mm] [inch] [mm] [inch] [mm] [lb] [kg]
2" 15.7 400 7.7 196 11.5 300 1.9 49 33 15
2.5" 16.1 410 8.5 217 12.0 310 2.3 59 44 20
3" 22.0 560 9.3 235 12.5 324 2.9 74 66 30
4" 24.4 620 11.1 281 13.1 337 3.8 97 119 54
5" 26.0 660 12.7 323 14.1 359 4.8 122 183 83
6" 27.2 690 13.8 350 15.0 374 5.8 146 223 101
8" 24.4 620 16.1 408 16.5 421 7.6 194 333 151
10" 27.2 690 18.3 479 20.0 508 9.6 243 531 241
12" 28.3 720 20.9 530 22.0 559 11.4 289 655 297
14" 29.9 760 22.4 568 23.7 603 12.5 317 798 362
16" 32.7 830 25.0 635 27.0 686 14.3 364 1105 501
18" 34.6 880 27.1 689 29.3 743 16.1 409 1389 630
20" 35.4 900 29.5 750 32.0 813 17.9 456 1695 769
24" 38.2 970 34.0 864 37.0 640 21.6 548 2438 1106
Table 4-6: Dimensions and weight in inch / mm and lb / kg
1 Di = inner diameter at flange face. Inner tube diameter may be smaller.
