INSTALLATION 2
9
OPTISONIC 7300
www.krohne.com09/2018 - 4002312802 - QS OPTISONIC 7300 R04 en
2.4 Storage
• Store the device in a dry, dust-free location.
• Avoid continuous direct sunlight.
• Store the device in its original packaging.
• Storage temperature: -50...+70°C / -58...+158°F
2.5 Transport
Signal converter
• Do not lift the signal converter by the cable glands.
Flow sensor
• Do not lift the flow sensor by the connection box.
• Use hoisting belts only.
• To transport flange devices, use lifting straps. Wrap these around both process connections.
2.6 Pre-installation requirements
Make sure that you have all necessary tools available:
• Allen key (4 and 5 mm)
• Small screwdriver
• Wrench for cable glands and for pipe mounting bracket (remote version only); refer to
Mounting the field housing, remote version
on page 15
Figure 2-6: Transport
INFORMATION!
To assure a quick, safe and uncomplicated installation, we kindly request you to make provisions
as stated below.
