2.9.5 Installation position
• Horizontal: install the flow sensor in a horizontal position in case of the presence of liquids.
• Vertically
+15
+15+15
+15° <
< <
< D < -15
< -15 < -15
< -15°
• Horizontal or vertical: allowed installation position in case of dry gas.
Figure 2-13: Installation position
Figure 2-14: Horizontal and vertical installation
