3 ELECTRICAL CONNECTIONS
18
OPTISONIC 7300
www.krohne.com 09/2018 - 4002312802 - QS OPTISONIC 7300 R04 en
CAUTION!
To ensure smooth functioning, always use the signal cable(s) included in the delivery.
Figure 3-2: Clamp the cables on the shielding bush
1 Cables
2 Cable glands
3 Grounding clamps
4 Cable with metal shielding bush
Figure 3-3: Connect the cables on the signal converter
INFORMATION!
Connect the cable on connector with similar numeral marking
