I - 3
General information
Technical data XXL R/GD 4XL-R/GD
Total length mm 9580 10480
Total width mm 2548 2620
Total height mm 3740 3990
Total height folded down mm 3040 3290
Platform height mm 1260 1580
Track width mm 1950 1950
Tyres 555/45-17 FRT 600/55-22.5/12PR
DIN capacity for dry material
(DIN 11741) approx. m3 31 36
KRONE protection from foreign objects Individual cutter protection Individual cutter protection
Cutting length for
20 cutters approx. mm 80 80
39 cutters approx. mm 40 40
Pick-up working width
(DIN 11200) mm 1800 1800
Power consumption approx. kW (HP) 95 (130) 105 (143)
Permitted laden weight kg 16.000 19.500
(19.500)
Loading time approx. min. 6-9 7-10
Unloading time approx. min. 4,5 5,5
Ground clearance of the
hydraulic articulated tow-bar approx. mm 750 750
Single- or double-acting
hydraulic connection with free
return must be available yes yes
1.2.9 Technical data
Not all weights and dimensions necessarily correspond
to the serial design and are not binding.
