4 Description of the Pump (Set)
19 of 60
Multi Eco
4.7 Dimensions and weights
Dimensions
For pump set dimensions refer to (ðSection9.3,Page53) .
Weights
Table5: Multi Eco D weights
Size Weight
[kg]
Multi Eco 33 D 11
Multi Eco 34 D 11
Multi Eco 35 D 11
Multi Eco 36 D 12
Multi Eco 65 D 12
Table6: Multi Eco E, P weights
Size Weight
[kg]
Multi Eco 33 E; P 11
Multi Eco 34 E; P 11
Multi Eco 35 E; P 11
Multi Eco 36 E; P 14
Multi Eco 65 E; P 14
Table7: Multi Eco-Pro weights
Size Weight
[kg]
Multi Eco-Pro 34 13
Multi Eco-Pro 35 13
Multi Eco-Pro 36 16
Multi Eco-Pro 65 16
Table8: Multi Eco-Top weights
Size Weight
[kg]
Multi Eco-Top 34 E 20 19
Multi Eco-Top 35 E 20 19
Multi Eco-Top 35 E 50 21
Multi Eco-Top 36 E 50 24
Multi Eco-Top 65 E 50 24
Multi Eco-Top 36 D 50 24
Multi Eco-Top 65 D 50 24
4.8 Noise characteristics
Table9: Surface sound pressure level L
wA
Size Noise characteristic
[dB]
Multi Eco 33 55
Multi Eco 34 55
Multi Eco 35 59
Multi Eco 36 67
Multi Eco 65 67
