5 Installation at Site
21 of 60
Multi Eco
5.2 Checks to be carried out prior to installation
Place of installation
WARNING
Installation on mounting surface which is unsecured and cannot support the load
Personal injury and damage to property!
▷ Use a concrete of compressive strength class C12/15 which meets the
requirements of exposure class XC1 to EN206-1.
▷ The mounting surface must have set and must be completely horizontal and
even.
▷ Observe the weights indicated.
1. Check the structural requirements.
All structural work required must have been prepared in accordance with the
dimensions stated in the outline drawing/general arrangement drawing.
5.3 Installing the pump set
WARNING
Excessive temperatures due to improper installation
Burns from touching hot surfaces!
Damage to the pump set!
▷ Install the pump set at distance of at least 30 mm from the wall in a dry, well-
ventilated room that is not at risk of flooding.
ü The place of installation has been properly prepared. (ðSection5.2,Page21)
1. Place the pump set in horizontal position.
2. Bolt down the feet of the pump set or membrane-type accumulator (Multi Eco-
Top).
(Except transportable version of Multi Eco)
5.4 Piping
5.4.1 Connecting the piping
WARNING
Impermissible loads acting on the pump nozzles
Burns from contact with fluid handled!
Damage to the pump set!
▷ Do not use the pump as an anchorage point for the piping.
▷ Anchor the pipes in close proximity to the pump casing.
▷ Observe the permissible forces and moments at the pump nozzles.
