KSB Multi Eco - Removing the Mechanical Seal and Rolling Element Bearings

7 Servicing/Maintenance
41 of 60
Multi Eco
7.4.5 Removing the mechanical seal and rolling element bearings
ü The stage casing has been removed. (ðSection7.4.4,Page39)
1. Remove and discard the support ring of mechanical seal 45-4.
2. Remove and discard the rotating part of mechanical seal 433.
3. Unscrew the fastening screws from the discharge cover.
4. Remove the discharge cover.
5. Remove the stationary part of mechanical seal 433 and thrower 270 and discard
thrower 270.
