7 Servicing/Maintenance
42 of 60
Multi Eco
6. Pull out the rotor.
7. Take out and discard flexible disc 931.
8. Pull off and discard rolling element bearings 321.01 and 321.02.
9. Remove and discard circlips 932.01 and 932.02.
7.4.6 General information/Safety regulations
WARNING
Improper lifting/moving of heavy assemblies or components
Personal injury and damage to property!
▷ Use suitable transport devices, lifting equipment and lifting tackle to move
heavy assemblies or components.
