KSB Multi Eco - Page 48

7 Servicing/Maintenance
48 of 60
Multi Eco
8. Mount the pump shroud on the discharge cover.
Make sure it is correctly seated!
9. Place new O-ring 412.01 onto the pump casing.
10. Fit the pump casing.
11. Screw the fastening bolts into the pump casing and tighten.
Tightening torque: 10 Nm!
