KSB Multi Eco - Page 54

9 Related Documents
54 of 60
Multi Eco
Multi Eco-Pro
Rc
1
/
4
Rc
1
/
4
=
141
36
≈370
20
10
Ø
M
H
=
160
95
58
L
1
L
2
68
B
A
(1)
A Suction nozzle B Discharge nozzle
(1) Two holes Ø 8
Table16: Dimensions in mm
Multi Eco-Pro Ø A
Suction nozzle
Ø B
Discharge nozzle
L
1
L
2
H ØM
34-1 G 1 G 1 151 387 215 118
35-1 G 1 G 1 180 415 215 118
36-1 G 1 G 1 208 467 230 140
65-1 G 1
1
/
4
G 11/4 208 467 230 140
Multi Eco-Top
l
1
l
2
d
1
h
2
h
1
d
2
57,5
R
1
/
4
R
1
/
4
e
A
B
B
(1)
(2)
A Suction nozzle B Discharge nozzle
(1) Four holes Ø 8 (2) Length 1.5 m
Table17: Dimensions in mm
Multi Eco-Top Ø A
Suction
nozzle
Ø B
Discharge
nozzle
d
1
d
2
l
1
l
2
h
1
h
2
e
34 / 20 Rp 1 G 1 260 202 570 155 525 425 28
35 / 20 Rp 1 G 1 260 202 570 155 525 425 57
35 / 50 Rp 1 G 1 360 280 650 235 620 525 17
36 / 50 Rp 1 G 1 360 280 650 235 620 525 46
65 / 50 Rp 1
1
/
4
G 1 360 280 650 235 620 525 46
