Part No. Comprising Description
503.01/.02 Impeller wear ring
904.06/.07 Grub screw
411.31
27)
/.32
27)
/.67
27)28)
Joint ring
260
29)
260 Impeller hub cap
550.87 Disc
906 Impeller screw
320.02/550
30)
320.02
31)
Angular contact ball bearing
550
32)
Adjusting washer
322.01 322.01 Cylindrical roller bearing
330 330 Bearing bracket
69.10 Protective cage
360.01/.02 Bearing cover
400.01 Gasket
412.22 O-ring
638 Constant level oiler
642 Oil level sight glass
710.21 Pipe
901.31/.37 Hexagon head bolt
913.03 Vent plug
916.46 Plug
914.01 Hexagon socket head cap screw
360.01/.02 360.01/.02 Bearing cover
400.01 Gasket
412.22 O-ring
914.01 Hexagon socket head cap screw
502.01/.02
33)
502.01/.02 Casing wear ring
904.03/.04
33)
Grub screw
503.01/.02
33)
503.01/.02 Impeller wear ring
904.06/.07
33)
Grub screw
507.01/.02 507.01/.02 Thrower
904.41/.42 Grub screw
542.02 542.02 Throttling bush
904.38 Grub screw
638 638 Constant level oiler
70-3
28)
70-3 Drain line
411.01 Joint ring
902.42 Stud
920.42 Hexagon nut
550.42 Disc
723.23 Flange
744.07 Gate valve
710.21 Pipe
723.21 Flange
411.41 Joint ring
724.01 Blind flange
901.20 Hexagon head bolt
920.20 Hexagon nut
550.20 Disc
831.02
28)
831.02 Fan impeller
832 Fan hood
485.02 Fan hub
27)
For bearing brackets B02 to B05 only
28)
Optional
29)
For bearing brackets B06 and B07 only
30)
For bearing brackets B03 and B05 only
31)
For bearing brackets B03 and B05 only
32)
For bearing brackets B03 and B05 only
33)
For impellers with balancing of axial thrust only
