Part No. Comprising Description
920.15 Hexagon nut
210 210 Shaft
920.21 Slotted round nut
931.01 Lock washer
940.01/.02 Key
230 230 Impeller
503.01/.02 Impeller wear ring
904.06/.07 Grub screw
411.31/.32
42)
Joint ring
260 260 Impeller hub cap
320.02 320.02 Angular contact ball bearing
322.01 322.01 Cylindrical roller bearing
330 330 Bearing bracket
69.10 Protective cage
360.01/.02 Bearing cover
400.01 Gasket
412.22 O-ring
638 Constant level oiler
642 Oil level sight glass
710.21 Pipe
901.31/.37 Hexagon head bolt
913.03 Vent plug
916.46 Screw plug
914.01 Hexagon socket head cap screw
360.01/.02
33)
360.01/.02
33)
Bearing cover
400.01 Gasket
412.22 O-ring
914.01 Hexagon socket head cap screw
502.01/.02
33)
502.01/.02
33)
Casing wear ring
904.03/.04
41)
Grub screw
503.01/.02 503.01/.02 Impeller wear ring
904.06/.07
41)
Grub screw
507.01/.02 507.01/.02 Thrower
904.41/.42 Grub screw
542.02 542.02 Throttling bush
904.38 Grub screw
550.87 550.87 Disc
638 638 Constant level oiler
70-3
42)
70-3
42)
Drain line
411.01 Joint ring
902.42 Stud
920.42 Hexagon nut
550.42 Disc
723.23 Flange
744.07 Gate valve
710.21 Pipe
723.21 Flange
411.41 Joint ring
24.01 Blind flange
901.20 Hexagon head bolt
920.20 Hexagon nut
550.20 Disc
831.02
42)
831.02
42)
Fan impeller
832 Fan hood
485.02 Fan hub
904.37 Grub screw
906 906 Impeller screw
42)
Optional
