OPERATION AND INSTALLATION MANUAL
COD. 091114 – COMPACK 2 ECO / SPECIAL - REV. 08 - DATE 10/2020 page 17 of 63
* When the environmental temperature is below 5°C, an ISO VG 32 lubricant must
** Value detected with the respective max working pressure
*** Noise measured in an open field at 1 metre from the unit ±3 dB(A) at maximum working pressure
Model
COMPACK ECO
Machine type
Oil injected screw compressor
Drive
Direct drive
Type of screw
ADAM V50
ADAM V50
Type of fluid handled
Air
Air
Flow rate (ISO 1217:2009 annex C)**
0,27 m
3
/min – 9,5 cfm
0,27 m
3
/min – 9,5 cfm
Max. working pressure
10 bar g - 145 psi g
10 bar g - 145 psi g
Min. working pressure
5 bar g – 72,5 psi g
5 bar g – 72,5 psi g
Maximum power consumption**
2,7 kW – 3,6 hp
3 kW – 4 hp
Max. air/oil outlet temperature
105 °C - 221°F
105 °C - 221°F
Max. environmental temperature
45 °C - 113 °F
45 °C - 113 °F
Min. environmental temperature*
5 °C - 41 °F
5 °C - 41 °F
Weight
40 kg – 88 lb
46 kg – 101,4 lb (2,5 lt)
52 kg – 114,6 lb (trolley)
78 kg – 172 lb (90lt)
40 kg – 88 lb
46 kg – 101,4 lb (2,5 lt)
52 kg – 114,6 lb (trolley)
78 kg – 172 lb (90lt)
Power supply voltage
230V/1ph/50Hz
400V/3ph/50Hz
Max. current consumption**
14,5 A
5,5 A
Electric motor protection rating
IP 54
IP 54
Insulation class
F
F
Service factor
S1
S1
Oil charge
1 litro
1,3 litri
Air outlet connection
1/4”
1/4”
Oil residue in air
< 5 ppm
< 5 ppm
Electric motor
MEC90
MEC90
Noise level***
< 65 dB(A)***
< 65 dB(A)***
