6 CONTROLS 34
6.4.2 Light switch
S00219-10
The light switch
1
is fitted on the combination switch on the left.
Possible states
Low beam on – Light switch in position
A
. In this position, the low beam
and tail light are switched on.
High beam on – Light switch in position
B
. In this position, the high
beam and tail light are switched on.
Headlight flasher. – Push the light switch into position
C
.
6.4.3 Hazard warning flasher switch
602606-10
The hazard warning flasher switch
1
is fitted on the combination switch on the left.
The hazard warning flasher is used to indicate emergency situations.
Info
The hazard warning flasher can be activated or deactivated while the ignition is
switched on or up to 60 seconds after the ignition is switched off.
Only keep the hazard warning flasher activated as long as necessary as it depletes
the battery.
Possible states
Hazard warning flasher on – All four turn signals and the green turn signal
indicator lights in the combination instrument flash.

KTM 1190 ADVENTURE R Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Transmission	6-speed
Fuel Capacity	23 liters
Dry Weight	217 kg
Front Suspension	WP USD Ø 48 mm
Wheelbase	1560 mm
Compression Ratio	12.5:1
Starter	Electric starter
Cooling	Liquid cooled
Lubrication	Forced oil lubrication with 3 oil pumps
Primary Drive	40:76
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Suspension Travel Front	220 mm
Suspension Travel Rear	220 mm
Ground Clearance	250 mm
Power	110 kW (150 hp)
Torque	125 Nm
Front Brake	2 x Brembo four-piston, radially mounted caliper, brake disc Ø 320 mm
Rear Brake	Brembo 2-piston caliper, 267 mm disc
ABS	Bosch 9ME Combined-ABS
Seat Height	890 mm (35 in)
Final Drive	Chain
Clutch	PASC (Power Assisted Slipper Clutch), hydraulically operated
