23 TECHNICAL DATA 221
Medium (standard) 170 N/mm (971 lb/in)
Spring length 185 mm (7.28 in)
Gas pressure 10 bar (145 psi)
Static sag
Standard 20 mm (0.79 in)
Race track mode 14 mm (0.55 in)
Fitted length 384 mm (15.12 in)
Shock absorber fluid ( p. 231) SAE 2.5
23.9 Chassis tightening torques
Remaining screws, chassis EJOT PT
®
K50x12 1 Nm (0.7 lbf ft) –
Remaining screws, chassis EJOT PT
®
K50x14 1 Nm (0.7 lbf ft) –
Remaining screws, chassis EJOT PT
®
K50x16 2 Nm (1.5 lbf ft) –
Remaining screws, chassis EJOT PT
®
K50x18 2 Nm (1.5 lbf ft) –
Remaining screws, chassis EJOT PT
®
K45x12 1 Nm (0.7 lbf ft) –
Screw, air filter box lid EJOT PT
®
K60 2 Nm (1.5 lbf ft) –
Screw, combination switch, left 5 Nm (3.7 lbf ft) –
Screw, fastening, flue exhaust valve
cover
EJOT SF
®
M4x6‑K 4 Nm (3 lbf ft) –
Screw, fuel tank cover, quick connect
nipple
EJOT PT
®
K60 2 Nm (1.5 lbf ft) –
Screw, tail light EJOT PT
®
K50x14 2.5 Nm (1.84 lbf ft) –
Screw, fixed grip, left M4 2 Nm (1.5 lbf ft) –
Screw, side stand switch M4 2 Nm (1.5 lbf ft) –
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft) –
