16 ELECTRICAL SYSTEM 136
Preparatory work
– Switch off all power consumers and switch off the engine.
– Remove the passenger seat. ( p. 99)
– Remove the front rider's seat. ( p. 100)
L01482-10
Main work
–
Remove screw
.
–
Lift cover
at the rear and pull toward the rear.
– Fold up the cover.
L01483-10
–
Disconnect negative cable
of the battery.
–
Remove positive terminal cover
and disconnect the positive cable from the battery.
–
Take the battery
out of the battery compartment.
