6 CONTROLS 33

6.3 Throttle grip

L01408-10

The throttle grip



is fitted on the right side of the handlebar.

6.4 Switches on the left side of the handlebar

6.4.1 Combination switch

The combination switch is fitted on the left side of the handlebar.

L01406-10

Overview of the left combination switch

1 Light switch ( p. 34)

2 Hazard warning flasher switch ( p. 34)

3 Menu switch ( p. 35)

4 Turn signal switch ( p. 35)

5 Horn button ( p. 36)
