23 TECHNICAL DATA 173

Nut, water pump impeller M6 10 Nm (7.4 lbf ft) Loctite

243™

Oil nozzle M6 6 Nm (4.4 lbf ft) Loctite

243™

Plug, water pump drain hole M6 8 Nm (5.9 lbf ft) –

Screw, alternator cover M6 12 Nm (8.9 lbf ft) –

Screw, bearing retainer M6 12 Nm (8.9 lbf ft) Loctite

243™

Screw, camshaft bearing bridge M6 11 Nm (8.1 lbf ft) –

Screw, camshaft, decompression shaft M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, chain securing guide M6 11 Nm (8.1 lbf ft) Loctite

243™

Screw, clutch cover M6 12 Nm (8.9 lbf ft) –

Screw, clutch spring M6 10 Nm (7.4 lbf ft) –

Screw, engine case M6x35 12 Nm (8.9 lbf ft) –

Screw, engine case M6x75 12 Nm (8.9 lbf ft) –

Screw, engine vent plate M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, freewheel gear retaining bracket M6 12 Nm (8.9 lbf ft) Loctite

243™

Screw, lock washer, engine sprocket M6 12 Nm (8.9 lbf ft) Loctite

243™

Screw, locking lever M6 12 Nm (8.9 lbf ft) Loctite

243™

Screw, oil pump M6 12 Nm (8.9 lbf ft) Loctite

243™

Screw, retaining bracket, shaft seal ring,

clutch cover

M6 11 Nm (8.1 lbf ft) Loctite

243™

Screw, shift drum locating M6 12 Nm (8.9 lbf ft) Loctite

243™

Screw, starter motor M6 12 Nm (8.9 lbf ft) –

Screw, timing chain tensioner M6 12 Nm (8.9 lbf ft) –

Screw, timing chain tensioning rail M6 12 Nm (8.9 lbf ft) Loctite

243™

Screw, unlocking of timing chain ten-

sioner

M6 10 Nm (7.4 lbf ft) –
