23 TECHNICAL DATA 174

Screw, valve cover M6 12 Nm (8.9 lbf ft) –

Screw, water pump cover M6 12 Nm (8.9 lbf ft) –

Nut, exhaust flange M8 22 Nm (16.2 lbf ft) –

Screw plug M8 12 Nm (8.9 lbf ft) –

Screw, balancer shaft gear M8 20 Nm (14.8 lbf ft) Loctite

243™

Screw, return spring, quick shifter M8 20 Nm (14.8 lbf ft) Loctite

243™

Stud, exhaust flange M8 22 Nm (16.2 lbf ft) –

Screw, conrod bearing M8x1 34 Nm (25.1 lbf ft) –

Oil pressure sensor M10 14 Nm (10.3 lbf ft) –

Rotor screw M10 110 Nm (81.1 lbf ft) Loctite

243™

Screw, camshaft drive sprocket M10 32 Nm (23.6 lbf ft) Loctite

243™

Screw, cylinder head M10 1st stage

30 Nm (22.1 lbf ft)

2nd stage

60 Nm (44.3 lbf ft)

Thread is oiled, head flat is

greased

Water temperature sensor M10 14 Nm (10.3 lbf ft) –

Screw plug, cam lever axis M10x1 9 Nm (6.6 lbf ft) –

Spark plug M12 15 Nm (11.1 lbf ft) –

Nut, inner clutch hub M16LHx1.5 120 Nm (88.5 lbf ft) Loctite

243™

Nut, primary gear/timing chain sprocket M16x1.5 120 Nm (88.5 lbf ft) Loctite

243™

Oil screen screw plug, small M17x1.5 12 Nm (8.9 lbf ft) –

Screw plug, alternator cover M18x1.5 10 Nm (7.4 lbf ft) –

Oil drain plug M24x1.5 15 Nm (11.1 lbf ft) –

Screw plug, alternator cover M24x1.5 10 Nm (7.4 lbf ft) –

Nut, balancer shaft gear M28x1.5 60 Nm (44.3 lbf ft) Loctite

243™

KTM 2015 RC 390 JP User Manual
