TECHNICAL SPECIFICATIONS – CHASSIS »
79
TIGHTENING TORQUES – CHASSIS 690 SUPERMOTO / 690 SUPERMOTO PRESTIGE 2007
Screw for side stand switch M4 Loctite 243 + 2 Nm
Spoke nipple M4.5/M5 5 Nm
Screw for fuel pump, pressure regulator M5 4 Nm
Screw for fuel level sensor M5 3 Nm
Screw for foot brake pedal surface M5 Loctite 243 + 6 Nm
Screw for plastic clamp brake line fork leg M5 2 Nm
Screw for heat protector on exhaust M5 Loctite 243 + 5 Nm
Screw for side cover M5 2 Nm
Screw for seat lock M5 Loctite 222 + 3 Nm
Screw for starter cable - starter M5 3 Nm
Pushrod ball joint foot brake cylinder M6 Loctite 243 + 10 Nm
Remaining screws for tank M6 6 Nm
Screw for compensating tank rear wheel brake M6 5 Nm
Screw for battery rack, control unit holder M6 3 Nm
Screw for fuel cock M6 6 Nm
Screw for front/rear brake disk M6 Loctite 243 + 14 Nm
Screw for foot brake cylinder M6 Loctite 243 + 10 Nm
Screw for horn M6 Loctite 243 + 6 Nm
Screw for license plate holder M6 8 Nm
Screw for lower radiator mount M6 5 Nm
Screw for magnetic side stand holder M6 Loctite 243 + 10 Nm
Screw for rectifier regulator M6 8 Nm
Screw for headlight mask M6 5 Nm
Screw for side stand bracket M6 Loctite 243 + 10 Nm
