TECHNICAL SPECIFICATIONS – CHASSIS »
80
TIGHTENING TORQUES – CHASSIS 690 SUPERMOTO / 690 SUPERMOTO PRESTIGE 2007
Screw for SAS valve M6 6 Nm
Nut for rear sprocket screw M8 Loctite 243 + 35 Nm
Nuts for header - cylinder head M8 copper paste + 25 Nm
evenly, do not bend washer
Screw for silencer exhaust clamp M8 25 Nm
Screw for header exhaust clamp M8 copper paste + 25 Nm
Screw for side stand spring bracket M8 Loctite 243 + 25 Nm
Screw for rear footrest support M8 25 Nm
Screw for rear footrest bracket M8 Loctite 243 + 25 Nm
Screw for upper triple clamp M8 12 Nm
Screw for lower triple clamp M8 15 Nm
Screw for fork stub M8 15 Nm
Screw for grip M8 6 Nm
Screw for steering stem clamping M8 20 Nm
Screw for header - silencer M8 copper paste + 25 Nm
Screw for handlebar clamp M8 20 Nm
Screw for upper subframe M8 Loctite 243 + 35 Nm
Screw for side stand bracket M8 Loctite 243 + 25 Nm
Screw for tank bearing M8 15 Nm
Screw for linkage bracket, front engine holder M8 Loctite 243 + 25 Nm
Screw for front/rear brake disk M8x1.25 Loctite 243 + 30 Nm
Engine mount screws M10 Loctite 243 + 45 Nm
Screw for upper/lower shock absorber M10 Loctite 243 + 45 Nm
Screw for handlebar mount M10 20 Nm
