TIGHTENING TORQUES – CHASSIS 690 SUPERMOTO / 690 SUPERMOTO PRESTIGE 2007
Screw for side stand M10 Loctite 243 + 35 Nm
Screw for front brake caliper M10x1.25 Loctite 243 + 45 Nm
Screw for lower subframe M10x1.25 Loctite 243 + 45 Nm
Lambda probe M12x1.25 24.5 Nm
Nut for frame - connecting lever - rocker arm - swinging fork M14x1.5 100 Nm
Nut for swing arm pivot M16x1.5 100 Nm
Nut for engine sprocket M20x1.5 Loctite 243 + 80 Nm
Screw for steering head M20x1.5 12 Nm
Adjusting ring for swing arm support M24x1.5 25 Nm
Screw for front wheel spindle M24x1.5 40 Nm
Nut for rear wheel spindle M25x1.5 90 Nm
Remaining chassis screws M5
M6
M8
M10
4 Nm
10 Nm
25 Nm
45 Nm
Remaining chassis screws M6
M8
M10
15 Nm
30 Nm
50 Nm
