7 COMBINATION INSTRUMENT 44
7.9 Coolant temperature indicator
401292-01
The temperature display consists of 13 bars. The more bars that light up, the hotter the
coolant. When all bars light up, the following warning note appears on the info display:
High Coolant Temperature.
Possible states
• Engine cold – Up to three bars light up.
• Engine warm – Four to ten bars light up.
• Engine hot – Eleven to thirteen bars light up.

KTM RC 125 Specifications

General

Displacement	124.7 cc
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Bore x Stroke	58 mm x 47.2 mm
Engine Type	Liquid-cooled, 1-cylinder, 4-stroke engine
Max Torque	12 Nm @ 8, 000 rpm
Front Suspension	WP upside-down fork
Rear Suspension	WP Monoshock
Front Brake	Single disc, 4-piston caliper
Rear Brake	Single disc, single-piston caliper
Frame	Steel trellis frame
Front Tire	110/70 R17
Rear Tire	150/60-17
