12 SERVICE WORK ON THE CHASSIS 96
12.16 Mounting the battery cover
L02141-10
Main work
–
Position battery cover
and pull toward the rear.
The battery cover engages with an audible click.
– Check the battery cover is seated correctly.
Finishing work
– Mount the front rider's seat. ( p. 83)
12.17 Removing the front spoiler
Preparatory work
– Remove the right side cover. ( p. 103)
– Remove the left side cover. ( p. 100)
G01029-10
Main work
–
Remove screws
.
