16 ELECTRICAL SYSTEM
196
16.12 Diagnostics connector
H01911-10
Diagnostics connector
1
is located under the front rider's seat.
16.13 Front ACC1 and ACC2
E01197-10
Installation location
–
Power supplies ACC1
1
and ACC2
2
front are located
under the coolant compensating tank.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM RC 390 2019 and is the answer not in the manual?

KTM RC 390 2019 Specifications

General IconGeneral
Engine TypeSingle Cylinder, 4-Stroke, DOHC
Displacement373.2 cc
Torque36 Nm @ 7000 rpm
Transmission6-speed
Fuel SystemElectronic Fuel Injection
Rear Brake230mm disc, single-piston caliper
ABSYes
Fuel Tank Capacity9.5 liters
Dry Weight147 kg
Seat Height820 mm
FrameSteel trellis frame
Bore x Stroke89 mm x 60 mm
Compression Ratio12.6:1
Front Tire110/70 ZR17
Rear Tire150/60 ZR17
Ground Clearance178 mm
Cooling SystemLiquid cooled
Power43.5 hp (32 kW) @ 9000 rpm
Front SuspensionWP USD 43 mm
Rear SuspensionWP Monoshock
Front Brake320 mm disc
Top Speed170 km/h (approx)
