23 TECHNICAL DATA
240
Screw, timing chain tensioner M6 12 Nm (8.9 lbf ft)
Screw, unlocking of timing chain
tensioner
M6 6 Nm (4.4 lbf ft)
Screw, valve cover M6 12 Nm (8.9 lbf ft)
Screw, water pump cover M6 12 Nm (8.9 lbf ft)
Nut, exhaust flange M8 8 Nm (5.9 lbf ft)
Screw plug M8 12 Nm (8.9 lbf ft)
Loctite
®
243™
Screw, balancer shaftgear wheel M8 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, spring thrust bearing of the
shift shaft
M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Stud, exhaust flange M8 22 Nm (16.2 lbf ft)
Screw, conrod bearing M8x1 34 Nm (25.1 lbf ft)
Coolant temperature sensor M10 14 Nm (10.3 lbf ft)
Oil pressure sensor M10 14 Nm (10.3 lbf ft)
Screw, camshaft gear wheel M10 36 Nm (26.6 lbf ft)
Loctite
®
243™
Screw, cylinder head M10 1st stage
30 Nm (22.1 lbf ft)
2nd stage
60 Nm (44.3 lbf ft)
Thread is oiled, head flat is greased
