KTM RC 390 2019 User Manual

TECHNICAL DATA 23
253
Screw, passenger foot pegs bracket M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, presilencer on frame M8 24 Nm (17.7 lbf ft)
Screw, rear brake disc M8 21 Nm (15.5 lbf ft)
Loctite
®
243™
Screw, retaining bracket on fuel
tank
M8 13 Nm (9.6 lbf ft)
Screw, shift lever M8 17 Nm (12.5 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8x1 30 Nm (22.1 lbf ft)
Loctite
®
204™
Nut, rear sprocket screw M8x1.25 27 Nm (19.9 lbf ft)
Loctite
®
243™
Fitting side stand M10 35 Nm (25.8 lbf ft)
Loctite
®
243™
Remaining nuts, chassis M10 50 Nm (36.9 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, side stand pivot M10 35 Nm (25.8 lbf ft)
Nut, side stand bracket M10x1.25 35 Nm (25.8 lbf ft)
Screw, front footrest bracket /
engine bearer
M10x1.25 49 Nm (36.1 lbf ft)
Nut, fork pivot M14x1.5 100 Nm (73.8 lbf ft)
