Kubota M8540 Workshop Manual

6-S14
M8540, M9540, WSM
FRONT AXLE
[3] SERVICING
(1) 4WD Model
Ball Bearing
1. Hold the inner race, and push and pull the outer race in all
directions to check for wear and roughness.
2. Apply transmission fluid to the bearing, and hold the inner race.
Then, turn the outer race to check rotation.
3. If there is any defect, replace it.
W1035672
Needle Bearing
1. Check the needle bearing for abrasion, color, change or other
damage.
2. If there is any doubt as to the condition of a needle bearing,
replace it.
W1035776
KiSC issued 09, 2008 A

Kubota M8540 Specifications

General

Engine Type	Diesel
Engine Model	Kubota V3800-DI-T
Engine Power	85 hp
PTO Power	72 HP
Drive	4WD
Hydraulic System	Open Center
3-Point Hitch	Category II
Displacement	230 cu in (3.8 L)
