Kwikset SmartCode Series - Install Batteries; Battery Installation; Automatic Bolt Direction Determination; Initiate Bolt Direction Routine

AA
1
2
-
+
1
2
EXTERIOR
INTERIOR
LOCK
Button
Tab
Battery Pack
LED
5
c.Donotdisturbtheunitforapproximately20secondsuntiltheinterior
GreenLEDashesfollowedbyabeep.Duringthistimethesystemwilldrive
theboltseveraltimes,willdetermine“doorhanding”,storedatainmemory
andexit.Itisveryimportantthatthisprocessisallowedtonish
properly.
8.Automatic-BoltDirectionDetermination(DoorHanding).
IMPORTANT:DONOTSKIPTHEFOLLOWINGSTEP.
LOCKWILLNOTBEABLETOOPERATEPROPERLY!
● In the steps below, the Smart-
Code mechanism automatically
determines the “door handing” and
sets the proper direction for motor to
rotate.
LEFT HAND DOOR
(LHD) (RHD)
RIGHT HAND DOOR
a.Pressandholdthe“LOCK”buttonontheexteriorkeypad,whilefullyin-
serting the battery pack into the interior assembly (the tabs on the pack must
faceout-seeillustration).
b.Whentheunitbeginstooperatethebolt,releasethe“LOCK”button.
7. Install batteries.
AlkalineBatteryWARNING:Donotdisposeofinre,recharge,
putinbackwards,disassemble,mixwithusedorotherbatterytypes.May
explodeorleakandcausepersonalinjury.
a. Install 4 new AA Alkaline batteries.
Install the new batteries as indicatedinillustration.Make
surebatterieslieatinholder.Forbestperformance,
rechargeable batteries are not recommended.
Continued
 
