KYMCO CV3 Series User Manual

3
Control Functions of Mechanism
23
4
17. Speedometer: The unit is represented in km/h or mph,
and must be set from the APP. When switching the
setting, all units used in the dashboard will be
switched simultaneously. (except that of tire pressure)
18. Odometer: Records the total accumulated mileage
travelled.
19. Tachometer: Indicates engine speed in rpm; each
scale multiplied by 1000rpm.
20. Power/Rain mode: The MODE button is located
among the left handlebar switches, and can be
switched between power/rain modes depending on
the driver’s need.
MODE button

KYMCO CV3 Series Specifications

General

Displacement	550.4 cc
Front Suspension	Telescopic fork
Rear Tire	160/60-15
Fuel Capacity	15.5 liters (4.1 gallons)
ABS	Yes
Max Power	51 hp @ 7500 rpm
Fuel System	Electronic fuel injection
Transmission	CVT
Front Brake	Dual disc
Rear Brake	Single disc
Weight	280 kg
Seat Height	795 mm
Max Torque	53 Nm @ 5750 rpm
Front Tire	120/70-15
