Front and rear brake shoes (drum brake)
inspection
When turn the adjusting nut fully to decrease
brake lever free play and the free play and the
free play exceeds the specification (1~2cm), it
means the brake shoe is worn out. Go to our
designated distributors or service stations for
brake shoe replacing.
110
(2)
(1)
(1) Wear indicator (2) Rear brake
Rear brake pads inspection (Disk brake)
A wear indicator is provided on each brake. The
indicators allows checking of brake pads wear.
Check the position of the indicator. If the
indicator reaches the wear limit line, ask a
KYMCO dealer to replace the pads.
