Wheel removal
1. Elevate the wheel by placing a suitable stand
under the frame.
2. Remove the nuts from the wheel.
3. Remove the wheel assembly.
Wheel installation
When installing the wheel, reverse the removal
procedure. Pay attention to the following.
Wheel nut torque:
Front:40Nm(4.0m-kg,30ft-lb)
Rear: 40 Nm (4.0 m-kg, 30 ft-lb)
(1) Safe nut
(1)
124
