(02) (01)(03)(04)
(05) (07) (08)
(06)
(01) Flag pole bracket
(02) Right footboard
(03) Indicator lamps
(04) Parking brake ( 90R)
(05) Parking brake ( 50R)
(06) Fuel fill cap
(07) Left footboard
(08)
MXER
MXER
Taillight/Stop light
13
