Kyocera ECOSYS FS-1135MFP Technical Reference Manual

Chapter 7 Emulation
7-2
Selecting an Emulation
When installing a printing system, you can select an emulation that best suits the require-
ment by the application software. In most cases, the emulation will be the factory default
setting (mode 6: HP LaserJet). Refer to the following diagram to locate the next level
emulation in case you need to change the emulation.
For example, in printing environments using the HP plotter model HP 7550A (KC-GL),
the user should select mode 8. In PostScript printing environments, mode 9 should be
selected (an option on some models) .
To set an emulation mode, send the printing system the FRPO commands listed in the
table below.
The emulation mode can also be changed from the printing system’s operator panel.
Table 7.1. Emulation Switching Command Sequence
Mode Emulation FRPO Commands
0 Line Printer !R! FRPO P1, 0; FRPO P3, 1; EXIT;
1 IBM Proprinter X24E !R! FRPO P1, 1; FRPO P3, 2; EXIT;
2 Diablo 630 !R! FRPO P1, 2; FRPO P3, 1; EXIT;
5 Epson LQ-850 !R! FRPO P1, 5; FRPO P3, 2; EXIT;
6 HP LaserJet !R! FRPO P1, 6; FRPO P3, 1; EXIT;
8 HP 7550A !R! FRPO P1, 8; FRPO P3, 1; EXIT;
9 KPDL !R! FRPO P1, 9; EXIT;

Kyocera ECOSYS FS-1135MFP Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Standard Memory	256 MB
Connectivity	USB 2.0, Ethernet
Scanner Type	Flatbed, ADF
Scan Resolution	600 x 600 dpi
Copier Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Maximum Paper Size	A4
Operating System Compatibility	Windows, Mac OS, Linux
Dimensions	494 x 430 x 448 mm
Print Speed	35 ppm
Standard Input Capacity	250 sheets
Copy Speed	Up to 35 cpm
Maximum Input Capacity	800 sheets (with optional paper feeders)
