Kyocera ECOSYS FS-1135MFP Technical Reference Manual

Path Mode Graphics
2-33
Figure 2. 34. Clipping Rectangle Example
Printing with Character Paths
When a resident scalable (outline) font is selected, you can treat a character as a path and
add it to the current path. The PRESCRIBE command is CPTH (Character PaTH).
Paths created with the CPTH command can be either stroked or filled. See the following
example.
!R! RES;
UNIT P;
NEWP;
PAT 26;
SFNT ’Helvetica-Bd’, 54;
PMZP 72, 144;
CPTH "xyz";
FILL 1;
PAGE;
EXIT;
Figure 2. 35. Character Path
Line 2 of this program sets the unit to printing system’s points (1 point=
1
/
72
inch), then
the NEWP command on line 3 empties the current path (if any), making ready for con-
struction of a new path. The PAT command on line 4 selects predefined pattern number
26 as the current fill pattern.

Kyocera ECOSYS FS-1135MFP Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Standard Memory	256 MB
Connectivity	USB 2.0, Ethernet
Scanner Type	Flatbed, ADF
Scan Resolution	600 x 600 dpi
Copier Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Maximum Paper Size	A4
Operating System Compatibility	Windows, Mac OS, Linux
Dimensions	494 x 430 x 448 mm
Print Speed	35 ppm
Standard Input Capacity	250 sheets
Copy Speed	Up to 35 cpm
Maximum Input Capacity	800 sheets (with optional paper feeders)
