Kyocera ECOSYS FS-2100D Service Manual

2P7/2R0/3PN
2-1-10
2-1-7 Eject/Feedshift section
The paper eject/feedshift section consists of the conveying path which sends the paper that has passed the
fuser section to the facedown tray, the faceup tray or the duplex conveying section.
Figure 2-1-19
Figure 2-1-20
4
5
6
3
2
9
8
10
1
7
1
2
3
4
5
8
9
7
10
6
1. Upper eject roller
2. Upper eject pulley
3. Actuator
(Eject full sensor (EFS))
4. Lower eject roller
5. Lower eject pulley
6. Top cover
7. DU feed pulley
8. Faceup roller
9. Faceup pulley
10. Feedshift guide
YC12-3
YC12-1
YC12-2
YC12-3
YC12-4
YC13-1
YC13-3
YC26-3
PAPFULN
OUTB3
OUTB1
OUTA3
OUTA1
FACEDDRN
FACEUDRN
EXITSENSN
EFS
EM
FSSOL
ES
EPWB
R-LPWB
