Kyocera ECOSYS FS-2100D Service Manual

2P7/2R0/3PN
1-4-31
(12)
Conveying clutch
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Conveying clutch and engine PWB (YC5)
2. Defective clutch. Replace the Conveying clutch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-40).
(13)
MP solenoid does
not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
MP solenoid and engine PWB (YC8)
2. Defective solenoid. Replace the MP solenoid.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-40).
(14)
Feedshift solenoid
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Feedshift solenoid and relay-L PWB (YC13)
Relay-L PWB and engine PWB (YC2/YC3)
2. Defective solenoid. Replace the Feedshift solenoid.
3. Defective PWB. Replace the engine PWB or the relay-L PWB and check for
correct operation (see page 1-5-40, 1-5-45).
(15)
The message
requesting paper to
be loaded is shown
when paper is
present on the cas-
sette.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
High voltage PWB and engine PWB (YC19)
2. Deformed actuator of
the paper sensor.
Check visually and replace if necessary.
3. Defective paper sen-
sor.
Replace the engine PWB or the high voltage PWB and
check for correct operation (see page 1-5-40,1-5-54).
4. Defective PWB.
(16)
The message
requesting paper to
be loaded is shown
when paper is
present on the MP
tray.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
MP paper sensor and relay-L PWB (YC8)
Relay-L PWB and engine PWB (YC2)
2. Deformed actuator of
the MP paper sensor.
Check visually and replace if necessary.
3. Defective MP paper
sensor.
Replace the MP paper sensor.
4. Defective PWB. Replace the engine PWB or the relay-L PWB and check for
correct operation (see page 1-5-40, 1-5-45).
Problem Causes Check procedures/corrective measures
