2PK/2PL/2PM/2PN
1-5-50
(2) Direction of installing the left cooling fan motor, right cooling fan motor
When detaching or refitting a fan motor, be careful of the airflow direction (intake or exhaust).
Figure 1-5-75
Right cooling
fan motor
Exhaust
Intake
Left cooling fan motor
