Kyocera ECOSYS M2035dn

2PK/2PL/2PM/2PN-3
2-4-3
(2) Repetitive defects gauge
* : The repetitive marks interval may vary depending on operating conditions.
First occurrence of defect
[24.99 mm/1"] Upper registration roller
[37.68 mm/1 1/2"] Lower registration roller
[62.8 mm/2 1/2"] Developing roller (developing unit)
[45.216 mm/1 3/4"] Transfer roller
[73.162 mm/2 7/8"] Heat roller (fuser unit)
[78.5 mm/3 1/16"] Press roller (fuser unit)
[94 mm/3 11/16"] Drum (drum unit)
