Kyocera ECOSYS P4040dn User Manual

Operation Panel
4-82
Error (Error tone setting)
When On is selected in this setting, a tone sounds when a problem such as running out of paper or a paper jam occurs
during printing. The default setting is On.
1 In the Buzzer menu screen, press  or  to select Error.
2 Press [OK]. The Error screen appears.
3 Press  or  to select whether the warning tone is enabled.
4 Press [OK]. The warning tone setting is set and the Buzzer menu
reappears.
Keyboard Confirm (Keyboard confirmation tone setting)
When On is selected in this setting, a tone sounds each time a USB keyboard is used. The default setting is Off.
1 In the Buzzer menu screen, press  or  to select Keyboard
Confirm.
2 Press [OK]. The Keyboard Confirm screen appears.
3 Press  or  to select whether the keyboard confirmation tone is
enabled.
4 Press [OK]. The Keyboard Confirm tone setting is set and the
Buzzer menu reappears.
RAM Disk Setting (Using the RAM disk)
The RAM disk is a memory space shared within the printer memory that can temporarily store print jobs. The stored print
job can then be used to print multiple copies of the job reducing the total amount of time required to print the whole job. It
acts similar to the SSD except that the data is effective only when the printer is powered up.
To use the RAM disk, activate and enter the desired size of the RAM disk in the manner described below. The maximum
RAM disk size can be calculated as follows:
When the RAM disk is activated = The maximum RAM disk size is 16 MB (when no options are attached.)
When the optional memory is installed, the setting range varies depending on the amount of optional memory.
By default, the RAM disk is set to On.
To activate RAM disk in the printer's memory, first you must set the RAM disk mode to On and set the desired data size for
the RAM disk as described in the following section. This allows you to perform the following operations on the RAM disk.
Error:
Off
01
On
02
*
Keyboard Confirm:
Off
01
On
02
*
Note The RAM disk is an allocated part of the printer’s memory.
IMPORTANT The RAM disk can not be used when an optional SSD is installed.
The RAM disk stores data only temporarily. When the printer is reset or turned off, the stored data will be erased.
The RAM disk allows some Job Box functions to be used.
The RAM disk is allocated from the printer memory available to users. If the size of the RAM disk is set too large, the
printing speed may decrease or the memory may become insufficient.

Kyocera ECOSYS P4040dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 297 mm
Custom media length	148 - 450 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor model	465
Processor family	PowerPC
Noise level (idle)	30 dB
Maximum internal memory	1280 MB
Sound pressure level (printing)	50.4 dB
Sound pressure level (quiet mode)	49.6 dB
Display	LCD
Certification	TUV, GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	14 W
Power consumption (printing)	586 W
Power consumption (PowerSave)	1.5 W
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.5 Leopard
Other operating systems supported	Android, iOS

Weight and Dimensions

Depth	410 mm
Width	469 mm
Height	320 mm
