Kyocera FS-9120DN User Manual

Chapter 3 Using the Operator Panel
3-35
Partition Size: The size of the written data in bytes.
Partition Type: The type of the written data i.e.,
whether it is host data (Data) or
font data (Font).
When the list of file names (partition list) for the hard
disk is printed, the message display returns to
Ready
.
It also prints out the Directory Status List to
confirm the directory or data that is written in PJL
or KPDL (PostScript).
2.2.10 Operating the RAM Disk
The RAM disk is a memory space shared within the printer
memory that can temporarily store print jobs. The RAM disk
can be used only for electronic sorting. The stored print job
can then be used to print multiple copies of the job reducing
the total amount of time required to print the whole job. It
acts similarly to the hard disk except that the data is effective
only when the printer is powered up.
To set up the RAM disk, the option hard disk must not be in-
stalled.
To use the RAM disk, activate and enter the desired size of
the RAM disk in the manner described below. The maximum
RAM disk size can be calculated as follows:
FS-9120DN:
Maximum RAM size = Total printer memory minus 36 MB
FS-9520DN:
Maximum RAM size = Total printer memory minus 24 MB
For example, if the total memory installed in your printer
(FS-9520DN) is 64 MB (Default), you can set 40 MB of RAM
disk. If you attempt to set the RAM disk size beyond this re-
striction, the printer automatically rounds it down so that the
size is always 24 MB less than the total printer memory. Once
the RAM disk size is set, the printer must be reset.
To activate RAM disk in the printer’s memory, first you must
use the printer’s menu selection system. The printer’s menu
selection system allows you to perform the following opera-
tions on the RAM disk.
• Setting RAM disk size
• Reading data
•Writing data
•Deleting data
• Printing of list of partitions
By default, the RAM disk is not activated (Off). To confirm the
RAM disk size or activate the RAM disk, proceed as follows:
Setting RAM Disk Size
Press the MENU key.
Press the  or  key repeatedly until RAM Disk
Mode > appears.
Press the ENTER key. A blinking question mark (?)
appears.
Press the  or  key to select On.
Press the ENTER key. A blinking question mark (
?
)
disappears and
>
appears on the right side.
Press the  key.
Press the  or  key repeatedly until >RAM Disk
Size appears. The data size also appears.
Press the ENTER key. A blinking cursor (_) appears.
Press the  or  key to display the desired size.
Definable RAM disk size: 0001 to 1024 (display of
size varies depending on the installed RAM size.)
Press the ENTER key. The selected RAM disk size is
activated.
Press the MENU key. The message display returns to
Ready.
RAM Disk Mode
Off
RAM Disk Mode
? Off
>RAM Disk Mode
? On
RAM Disk Mode >
On
>RAM Disk Size
0028 MByte
>RAM Disk Size
0028 MByte
1
2
3
4
5
6
7
8
9
10
11

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
