Chapter 5 Maintenance
5-2
Grasp the handle on the toner container, push the
lock lever up again and gently lift the toner container.
Figure 5-3
Seal up the old toner container with the supplied
plastic bag and dispose of it.
Figure 5-4
Lightly tap the new toner on the top 5 to 6 times.
Figure 5-5
Thoroughly shake the toner container (in the direc-
tion of the arrow) ten times or more to loosen and
mix the toner inside.
Figure 5-6
Grasp the handle on the toner container and insert
the toner container along the rail of the printer.
Figure 5-7
When inserting, be sure that the gear side of the
toner container faces the printer. Leave the front
cover open to allow insertion of the waste toner box.
Figure 5-8
Hold the toner container using both hands and fully
insert it into the printer.
Figure 5-9
Remove the old waste toner box as shown in the fig-
ure.
Figure 5-10
3
4
5
6
7
Gear Side
To the Printer
8
9
To Next Page
