Kyocera FS-9120DN User Manual

Chapter 5 Maintenance
5-4
Remove the blue colored cleaning brush.
Figure 5-17
Pull up the lock lever on the left side of the printer,
and open the left cover 1.
Figure 5-18
Clean the separator by moving the cleaning brush
from left to right along with the separator.
When removing jammed paper, be careful not to touch
the printer drum. This can cause printer malfunction.
Figure 5-19
Replacing of toner and cleaning of the internal parts
of the printer are completed. Close the front cover
and the left cover 1.
Allow approximately five minutes before using the
printer until the main charger unit has dried up.
NOTE
16
17
18
19

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
