Kyocera FS-9500DN Installation Guide


Removing the Tapes
1
Remove the tape holding the front cover.
2
Remove the tape holding the MP (Multi
Purpose) tray.
3
Remove the four tapes holding the paper
cassettes.
4
Remove the tapes holding the left cover.
5
Pull out the upper paper cassette and
remove the two tapes holding the bottom
plate.
6
Pull out the lower paper cassette and
remove the two tapes holding the bottom
plate.
Paper Cassettes
MP Tray
Front
Cover
Left Cover 1
Paper Cassette


Kyocera FS-9500DN Specifications

General

Brand	Kyocera
Model	FS-9500DN
Category	All in One Printer
Language	English
