Replacement and Adjustment
61
FCU
1. Rear cover (→ p.16)
2. Controller box cover (→ p.57 "Controller Board")
3. Controller bracket (→ p.59 "EGB (Engine Board)")
4. FCU [A] (
x 4)
Interlock Switches
1. Operation panel (→ p.17)
2. Rear cover (→ p.16)
3. Left cover (→ p.18)
4. Remove the spring [A].
5. Interlock switch base [B] (
x 4, all s)
